PUXING PX-729 UHF 400-470Mhz 16 Channels + earpiece
PUXING PX729 UHF 400-470Mhz 16 Channels + earpiece
1.Frequency range: 400-470Mhz
2.Side button 2 and side button 3 can be programmable by PC software to these functions:
Monitor, squelch on/off, scan on/off, scan temporary delete, high/low power, talk about, Reverse frequency, VOX on/off
3. Those functions can be programmable through PC software Tx total time(s)， squelch， VOX gain level， band width， Tx power rank， beep
4. UHF 4W output power
5. 16 memory channels
6. Built-in 50 groups of CTCSS and 104 groups of DCS
7. Data password for programming
8. Comes with 1200mAh Lithium-ion battery
9. Built-in VOX sensitivity 0-9 levels
10 Scan function
11. Programmed by PC
13. Adjustable power high/low
14. Adjustable squelch level (0 to 9)
15. Busy channel lockout
16. Reverse frequency function
17. DTMF ANI Encode(pre-only， post-only and both)
18. TOT function
19. Loud speaker with clear communication
2.Side button 2 and side button 3 can be programmable by PC software to these functions:
Monitor, squelch on/off, scan on/off, scan temporary delete, high/low power, talk about, Reverse frequency, VOX on/off
3. Those functions can be programmable through PC software Tx total time(s)， squelch， VOX gain level， band width， Tx power rank， beep
4. UHF 4W output power
5. 16 memory channels
6. Built-in 50 groups of CTCSS and 104 groups of DCS
7. Data password for programming
8. Comes with 1200mAh Lithium-ion battery
9. Built-in VOX sensitivity 0-9 levels
10 Scan function
11. Programmed by PC
13. Adjustable power high/low
14. Adjustable squelch level (0 to 9)
15. Busy channel lockout
16. Reverse frequency function
17. DTMF ANI Encode(pre-only， post-only and both)
18. TOT function
19. Loud speaker with clear communication
GENERAL
| |
Frequency Range
|
400-470MHz
|
Operating Voltage
|
-20℃~+50℃
|
Operate Mode
|
Simplex or Semi-duplex
|
Dimension
|
114mm x 59mm x 34mm
(Not included antenna)
|
Weight
|
190g(Including battery)
|
Antenna Impedance
|
50 Ω
|
TRANSMITTER
| |
Frequency Stability
|
±2.5PPM
|
Output Power
|
4W
|
Max Frequency Deviation
|
≤5KHz
|
Audio Distortion
|
≤3%
|
Modulation Character
|
+3dB~-3dB
|
Adjacent Channel Power
|
≥70dB
|
Spurious Radiation
|
≤7.5uW
|
Occupied Bandwidth
|
≤16KHz
|
RECEIVER
| |
RF Sensitivity
|
＜0.2uV
|
Audio Distortion
|
≤3%
|
Audio Response
|
+2dB~-10dB
|
Co-Channel Rejection
|
≥-8dB
|
Adjacent Channel Selectivity
|
≥60dB
|
Intermodulation Rejection
|
≥65dB
|
Spurious Response
|
≥70dB
|
Blocking
|
≥80dB
|
